2012 – Year for mHealth?

2012 – Year for mHealth?

I received several items in my email regarding different organizations’ proclamations for 2012.  Most of them predict that 2012 will be the year for mHealth to ‘break-out.’  Here are 5 examples:

  1. HIMSS 2012 is focusing on mHealth with several sessions and will have a kiosk on the vendor floor which features speakers on the mobile aspect of healthcare
  2. AAMI has published in their IT World column a synopsis of mHealth (requires login credentials)
  3. Here in Europe, the Mobile World Congress, Barcelona Feb 2012, sponsored by the GSM Association, has a track devoted to mHealth (filter for Mobile Health), a day of demonstrations and a specific plan on embedded mobile medical functionality.
  4. Additionally, the FDA has come out with draft guidance and has promised final guidance regarding mobile medical apps.  The European Commission has entered into an MOU with the HHS to work together on the regulatory aspects of healthcare.  I wouldn’t be surprised if they come out with similar regulatory guidance regarding mHealth as that promulgated by the FDA.
Share
Read More

Medical Device Open Source Frameworks

The Big Picture

Medical device interoperability and standardization is a hot topic, and with the efforts surrounding adoption of the 11073 standard, IHE and patient care device frameworks, and the drive towards implementing electronic medical records, the field has become essential to the future of the healthcare industry. Yet, as we look to realign medical devices and their communication mechanisms away from proprietary intercommunication and towards standards-based communication, we should think “outside the box” to other fields, technologies and technical disciplines for inspiration and guidance on best practices. Perhaps an obvious one that comes to mind is the USB 2.0 standard. The simple idea being proffered is the ability to plug a medical device into a computing platform and have it recognized and joined automatically to the operating system. While we are a long way from this vision as a universal standard, there is ample evidence to demonstrate its feasibility in the existing Windows and MAC OS architectures today.

Driver Bundling

Key to the seamless and universal use and acceptance of USB devices is the bundling of device drivers delivered as part of base operating systems. When a new device is developed, it could be adopted for incorporation within the base Windows and Mac operating system environments. However, even before that adoption, manufacturers of these drivers could consider bundling them as part of hardware delivery. The drivers could be installed at run time or prior to usage and, from there, no other special attention would be required: attaching a medical device to an accompanying computing platform would automatically result in that device “joining” with the base operating system. The challenge, of course, is how best to develop drivers that support consistent and common access to data. While the common Patient Care Device (PCD) framework fosters such an idea, it has yet to be realized as a universal standard.

One theme embodied by the IHE medical device connectivity demonstrations featured at HIMSS 09 (pdf) in Chicago was that of following a patient from admission through a critical care room, in which patient information was gathered at the bedside from and to the various medical devices present there, including infusion, bed, monitor, and mechanical ventilation. The ability to collect and integrate these data into a bedside electronic health record was accomplished in concert among the several medical device manufacturers through access to the communication frameworks peculiar to the many vendors participating in the demonstration. The bundling of device drivers and publishing of a common syntax required to communicate with the various devices could provide a starting point for enabling universal biomedical device communication.

Share
Read More

Interoperability – Barriers to Adoption

There’s been some great comments on the recent post about the announcement of MD FIRE. That plus some other activities I’ve been involved in have inspired some thoughts on barriers to adoption for medical device interoperability.

For this discussion, interoperability refers to the ability of a medical device to be controlled by another medical device or third party information system. Medical device systems from a single vendor frequently include interoperability between the medical devices and applications running on general purpose computers, but since all the components are from the same vendor I’m excluding them from this discussion.

Like everything else, medical device interoperability will walk before it runs. In a recent comment, JimW suggests that MD FIRE’s focus is on driving the adoption of, “tightly coupled, low latency, deterministic connection[s].” I beg to differ; I found the MD FIRE text to be very general and that it avoided any kind of design solution whatsoever. Further, it is interesting that what little multi vendor interoperability that is actually on the market, is based on “tightly coupled, low latency, deterministic connection[s].” The example that comes to mind (actually the only one I can think of right now) is the use of CANopen to integrate radiographic equipment with contrast injectors in diagnostic imaging. Perhaps someone can provide additional examples.

Jim is right that such interoperability presents considerable product design and verification challenges, which is why I think that a different kind of interoperability will broad gain market traction before designs with tightly coupled deterministic connections. If you’ve heard Julian Goldman speak on this topic, he provides numerous examples of interoperability that revolve around simple safety interlocks like:

  • Using a patient monitor to cease therapy delivery (and sound an alarm, of course) on a PCA pump when respiratory arrest is detected,
  • Linking a heart lung machine and ventilator in surgery to ensure that one is turned on when the other is turned off, and
  • Linking diagnostic imaging with a ventilator to ensure ventlation is restarted after it is stopped to reduce motion artifact during imaging.

A portion of the 500 patients who die unnecessary deaths every day in U.S. hospitals are killed because simple safety interlocks like these don’t exist. Why? Clearly such interoperability is not rocket science.

Share
Read More

LiveData Advances Medical Device Interoperability

LiveData-Operating-Room-ofthe-Future

Great news in Healthcare IT News:

LiveData has been awarded a $70,000 Small Business Innovation grant in order to
develop a plug-and-play feature to implement standards for OR workflow
and medical device interoperability. The plug-and-play feature will enable devices to work together, to
create safety interlocks, and help ensure that clinicians make
decisions based upon all available information.

LiveData’s provides data integration, mostly in the surgical suite. Unlike video systems from Stryker and many others, LiveData combines real time medical device data with IT systems (EMR, PACS, etc.) and video.

LiveData will team with Draper Labs, Massachusetts General Hospital and CIMIT to do feasibility work in the medical device plug-and-play architecture called the Integrated Clinical Environment or ICE. LiveData will provide the software foundation for the grant project.

Share
Read More

Day 2 Keynote: John Rushby on Accidental Systems

HCMDSS-MDPnP-logo

Self proclaimed the, “oldest guy with a computer science degree,” John Rushby with SRI International started the second day with a presentation on Accidental Systems. Using aviation as a model, Rushby discussed interactive complexity and system failures. Exploring the causes of accidents, Rushby noted, “that sufficiently complex systems can produce accidents without a simple cause.” He related aviation failures to health care, noting that in many patient safety incidents, it is the system that fails rather than the clinician.

Aviation is a good model because the extensive reporting of both failures and incidents. Incidents are “near misses” rather than actual accidents. In aviation, because there was no crash, incidents are a rich source of reliability and failure data. He noted that the scarcity of near misses in health care (i.e., adverse events) makes similar analysis much more difficult.

Interactive complexity and tight coupling were noted as important factors to system safety. He then went through a number of failure scenarios in military aviation, demonstrating how complex systems can fail due to a lack of understanding interactions among various variables.

“Nearly all failure indications were not due to actual hardware failures, but to design oversights concerning unsynchronized computer operation.”

Rushby noted that we are pretty good at building and understanding components. But systems are about the interactions of components that manifests “emergent behavior.” We are not so good at understanding this because many interactions are unintended and unanticipated; only some are the result of component faults. There are often multiple and latent faults, and they can malfunction or exhibit an unintended function rather than a simple and obvious loss of function. Many failures are simply due to . . . complexity.

Unlike medical devices, the FAA certifies components only as part of an airplane or engine. That’s because it is not currently understood how to relate the behavior of a component in isolation to its possible behaviors in a system (i.e., in interaction with other components).

So, what are we doing in medical devices? We’re making components and plugging them together, creating “accidental systems.” These medical device systems are created without conscious design. The resulting interconnects produce desired behaviors – most of the time – but may promote unanticipated interactions leading to system failures or accidents.

The solution is simple; we just need to think it all through before we build it. There are two problems with this. First, it’s not known how to do this in general due to the complexity. Second, in health care we regulate components that are then assembled into accidental systems.

Rushby went on to describe some partial techniques for improving the safety of systems. Modes of interaction are key. Examples include interaction:

  • Among computational components
  • Through shared resources (e.g., the network)
  • Through the controlled plant (the patient)
  • Through human operators
  • Through the larger environment

Computer scientists have worked out how to predict and verify the combined behavior of interacting systems – sometimes. One method is called “assume/guarantee reasoning.” This method and others can be employed as an informal method or formally. Other formal methods include automated theorem proving, model checking and static analysis.

A cool new technology is “assumption generation.” This is well suited to human physiology, which can be quite variable – unlike a radar or jet engine. Using this engine you can define the loosest set of variables. Assume/guarantee reasoning combines a model or specification of your component(s) that includes assumptions about its environment. The assumed environment can be made part of the component specification using techniques like interface automata. (Interface automata (IA) is a light-weight formalism used to describe the temporal interface behaviors of software components.) The IAs of various components can be combined to create a state machine that can verify that a collection of components satisfy each others IAs. Data types and a state machine are extracted from these assumptions with the goal of creating a high confidence in system operation across the assumed environmental range (the assumption guarantee).

He also offered some simple tips to reduce interactive complexity:

  • Send sensor samples with use-by date rather than time stamp
  • For sensor fusion, send intervals rather than point estimates
  • Define data with respect to an ontology, not just basic types
    • E.g., raw output of blood pressure sensor vs. corrected for bed height
  • Critical things should not depend on less critical things
    • E.g., intervention for low blood pressure depends on blood pressure which depends on bed height sensor
    • Consequently, the bed height sensor is as critical as the blood pressure intervention or alarm

A key challenge with medical devices lies in the need to integrate device systems with other information technology infrastructure to facilitate the communications and sharing of data. Interaction through shared resources becomes a major factor in safe and effective systems engineering. The concept of partitioning went to the heart of the trade off between specialized embedded systems and general purpose computing platforms – or to look at it another way, between a standalone system and a medical device system deployed on a shared enterprise infrastructure.

Assume/guarantee reasoning is about computational interactions and relies on there being no paths for interaction other than those intended and considered. But commodity operating systems and networks provide lots of additional and unintended paths – hard to model variability. Typically, A and B get disrupted because X has gone bad and the system did not contain its fault manifestations. So safety- and security-critical functions in airplanes, cars, military, nuclear power etc. don’t use Windows, Ethernet, CAN etc. Avionics and military high-reliability applications are highly partitioned using very specialized system software, architectures and rigorous verification and validation. These make the world safe for assume/guarantee reasoning but are too expensive (and overkill) for medical device interoperability.

Contention on shared resources is a classic example where assume/guarantee reasoning breakdowns. An approach to solving this problem is interaction through a controlled plant. In medical devices, the controlled plant is the patient’s body. Medical device development would involve controller and plant models. A plant model may include only a few physiological parameters. Different devices will have different plant models and may be ignorant of other devices’ parameters – yet will interact in actual use.

Obvious perils include normal but unmodeled interactions, especially in the presence of faults. But problems can also occur due to inferior outcomes from lack of beneficial interaction, e.g., a harmonic relation between heart and breathing rates (Buchman).

Rushby’s final interaction is human interaction, with humans as cognitive agents (users) rather than the plant (or patient). Many things attributed to human error are in fact gross design errors. Even safety interlocks can introduce errors if the operator does not understand why an action is or is not happening. These kinds of problems suggest we may not be able to rely on skilled human intervention once we introduce automation – unless we design it right.

Modeling mental models can minimize human error. Operators use mental models to guide their interaction with automated systems. Problems arise due to divergence between an operator’s mental model and the actual behavior of the device or system. Design engineers can represent plausible mental models as state machines, e.g., use the training manual, and then simplify using insights of Denis Javaux. Then compare all behaviors of the mental model against the actual automation (using model checking). Divergences between the mental model and actual operation represent your automation “surprises.”

Beyond specific interactions, there is the larger environment. The purpose of a system is to change some relationships in the environment external to the system. So requirements specification should focus on those changes. But changing intended relationships may also change unintended ones. Requirements engineering should focus on these issues where unintended relationships can result in failures. This can be done by building models of the environment and exploring interactions. Model checking and other formal methods allow exploration of all possible behaviors.

So, now we have these various sources of unintended interactions and suggested some ways to detect and avoid them. The next challenge is to provide assurance that we’ve detected and avoided unintended interactions. All assurance is based on arguments that purport to justify certain claims, based on documented evidence. There are two approaches to assurance: implicit (standards based), and explicit (goal-based).

Aviation and security use a standards-based approach to software certification. In this approach, the applicant follows a prescribed method (or processes) to deliver prescribed outputs like documented requirements, designs, analyses, tests and outcomes, traceability, etc. Standards usually define only the evidence to be produced. The claims and arguments are implicit. Hence, it is hard to tell whether given evidence meets the intended use. This approach works well in fields that are stable or change slowly. A standards-based methodology tends to institutionalize lessons learned and best practices, but is less suitable with novel problems, solutions, and methods – like medical device interoperability.

The goal-based approach involves the applicant developing an assurance case whose outline form may be specified by standards or regulation. This approach makes an explicit set of goals or claims, and provides supporting evidence for the claims and arguments that link the evidence to the claims. Underlying assumptions and judgments are explicitly and unambiguously stated. This approach should allow different viewpoints and levels of detail. In practice, the case is evaluated by independent assessors who evaluate claims, evidence, and argument.

So what should evidence look like? There are two types of relevant evidence, evidence about the process, organization, people, and evidence about the product. Certification reviews are based on human judgment and consensus, e.g., requirements inspections, code walk throughs. Analysis can be repeated and checked by others, and potentially by machine. Formal methods/static analysis and tests are also used.

The interesting opportunity is to create a science of certification. Certification is ultimately a judgment that a system is adequately safe/secure/whatever for a given application in a given environment. But the judgment should be based on as much explicit and credible evidence as possible. A Science of Certification would be about ways to develop that evidence.

The bottom line is that there is enough damage caused by the practice of medicine that the introduction of inherently flawed medical device systems provides a net improvement. Consequently, there is no immediate requirement to rush to implement the kind of systems engineering and certification used in aviation or other high reliability endeavors.

A worst case scenario is a medical device system that results in death or injury to multiple patients – like when all the passengers are lost in a catastrophic airplane failure. This could quickly shift the health care environment where aggressive safety engineering is required.

All of this flies in the face of current software licensing via the ubiquitous EULA. The typical EULA asserts extensive liability limitations. Software vendors need to start making specific claims and backing them up with evidence.

Questions:
Given the interactions discussed, how is criticality addressed? There is no simple answer to that – one way is to calculate all the paths that this could occur and ensure all the paths are workable. In the context of systems it’s really hard to know how to do these things.

A CANopen proponent witnessed to the gathered multitude about the use of CAN in high-reliability systems like helicopters, naval ships, etc. Rushby noted that this field is not without controversy, but noted that CAN is used but that he would prefer not to fly on an airplane using CAN.

A group has been working on an ICE standard on medical device interoperability. There is a requirement in the standard for the vendor to create a mental model, and a fall-back mode in the event of unanticipated failure. Tight coupling is inherent in close loop control. Adding slack into such a system may be advantageous in accommodating human operator variability.

What is the possible impact on medical devices of the sometimes draconian measures that aviation uses for time-sliced partitioning? This approach is very costly to developers, placing many constraints upon the engineer. The flexibility inherent in human physiology may be better served by an approach that is different from time-slicing partitioning.

How close do you think we are to the “science of certification?” Rushby said he thinks we’re far away from that. Much if this is due to the transformative change in the aviation industry. There is also much yet to be learned about controller-synthesis, and how it would roll up into a certification science.
